Commercial Electric Boiler

Commercial Electric Boiler

The Commercial Electric Boiler designed for industrial and commercial use, it heats areas up to 4,000 ㎡,providing efficient floor heating and hot water. It uses patented electric heating technology for central heating via radiators or underfloor heating.

  • Electric boilers are exceptionally efficient, nearing 99%.
  • Can connect with the indirect water heater tank or buffer tanks for domestic hot water.
  • Unique patent Heating Element, high heating efficiency.
  • Double dry-heating protection function.
  • Automatic anti-freezing function.
  • Fault auto-detection technique.

Additional information

Rated Power (kW)

54KW/ 108KW/ 162KW/ 216KW/ 270KW/ 324KW

Voltage (V)

400V 3~

Working Temp. Range

30-80°C (in radiator mode) 30-60°C (in floor heating mode)

Temp. Difference Setting Range

5-30°C

Inlet Outlet Connector

DN25(54KW),DN40(108KW), DN65(162KW,216KW,270KW,324KW)

Product Size

500x340x650mm(54KW), 600x600x1180mm(108KW), 1070x600x1180mm(162KW,216KW), 1550x600x1180mm(270KW,324KW)
